MC4 Panel connector 1500V LPVM01A0001&LPVF01A0001

MC4 Panel connector 1500V LPVM01A0001&LPVF01A0001

MC4 Panel connector 1500V LPVM01A0001&LPVF01A0001

料号:LPVM01A0001

适配:LPVF01A0001



交期:14天

立即咨询 暂无内容

产品描述

技术指标:

Specifications

  1. RatIng Current∶ 40A(2.5mm²、4.0mm²、6.0mm²)

  2.rated voltage: 1500V(TUV)

  3.Test voltage: 8kV(50Hz,1min)

  4.Contact Reslstance∶ <0.5mΩ

  5,Contact material: Copper,Tin plated

  6.Degree of protection: IP2X(Not plugged in)/P68(Put together)

  7.Safery dlass: Il

  8.Insulation material: PPE

  9.Flame class: UL94V-0

  10.Insulation force; 50N Max

  11.Withdrawal force: 50N Min

  12.Ambient temperature range: 40℃℃ to+90°C (IEC/CEl)

  13.Suitable cable cross sections∶2.2/4.0/6.0mm²AWG14/12/10(Ø4.5-Ø8.5) 14.Connecting system
