MC4 Cable Connector 1500V LPVM01A0003 / LPVM01A0002

MC4 Cable Connector 1500V LPVM01A0003 / LPVM01A0002

MC4 Cable Connector 1500V  LPVM01A0003 & LPVF01A0002

料号:LPVM01A0003

适配:LPVF01A0002


交期:14天

产品描述

技术指标:

Specifications

  1. RatIng Current∶ 40A(2.5mm²、4.0mm²、6.0mm²)

   2.rated voltage: 1500V(TUV)

   3.Test voltage: 8kV(50Hz,1min)

   4.Contact Reslstance∶ <0.5mΩ

   5,Contact material: Copper,Tin plated

   6.Degree of protection: IP2X(Not plugged in)/P68(Put together)

   7.Safery dlass: Il

   8.Insulation material: PPE

   9.Flame class: UL94V-0

   10.Insulation force; 50N Max

   11.Withdrawal force: 50N Min

   12.Ambient temperature range: 40℃℃ to+90°C (IEC/CEl)

   13.Suitable cable cross sections∶2.2/4.0/6.0mm²AWG14/12/10(Ø4.5-Ø8.5)

   14.Connecting system
